29 Electrical Panel Label Requirements

When the exception to 11016b is leveraged and nfpa 70e is used to create the label a date is not required. The width of working space in front of the electric equipment shall be the width of the equipment or 762 mm 30 in whichever is greater.

Safety Signs Safety Tags And Safety Labels By Accuform Signs

The panel door must be able to open at least 90 degrees.

electrical panel label requirements. Thus many employers are also labeling bus ducts and other electrical equipment not specifically called out in the nec. While a 120v system is usually wired in black if you have a 120240v delta with a high leg then the phases end up being in black orange or blue. Labeling is required for any piece of electrical equipment that is likely to require examination adjustment service or maintenance while energized creating the potential for an arc flash incident to occur.

When you have an electrical problem and need to shut off a circuit you should be able to identify the controlling circuit breaker immediately by looking at the panel index. The electrical code requires you to label or index your panel. With regards to enforcing 1910132 and the subpart s standards the ppe requirements contained in subpart s would prevail over the general requirements contained in 1910132 where both standards would apply to the same condition practice control method etc.

Breaker panel must be at least 4 feet off the ground but no higher than 6 feet. In all cases the working space shall permit at least a 90 degree opening of equipment doors or hinged panels. This available shortcircuit current is first determined at the secondary termi nals of the electric utility transformer as given by the electric utility engineer.

The 120v system is usually wired in black red and blue while the 277v version is wired in brown orange and yellow. Working space around the breaker panel must be at least 30 inches wide and 72 inches from the ground up. The last part of the positive text of 11016b is the date.

Available shortcircuit current is the current in amperes avail able at a given point in the electrical system. A simple label attached to the front of the panel is all that is required. The only time a date is required to be placed on this label is when the positive text of 11016b is applied to create a label.
